Fit

Fits the image in a box with padding when needed

Resizes the image to fit into a specified width and height box, adds padding (image or solid color) to keep proportions, and delivers the resulting image via CDN.

func=fit

Please note that by default, smaller images will not be upscaled to fit the box. If you want to enable this behavior, you need to use fit_enlarge=1. along with func=fit.

The padding can be customized using the following additional operations:

Operation
Syntax
Description

gravity

gravity=X X=[north|south][east|west]

sets the position of the image in the fit box

margin

margin=X

defines a minimum margin when fitting the image in the new canvas

solid background

bg_color=X | bg_colour=X X={hex color}|auto

defines a background color with a hex code, color name or automatically, based on the image palette

blurred background

bg_img_fit=1

sets blurred image background

bg_blur=X

applies Gaussian blur to the background image

bg_opacity=X X=0..1

specifies background image opacity

bg_colorize=X | bg_colourise=X

defines a color to tint the background image

bg_gravity=X X=[north|south][east|west]

defines the positioning of the background image within its container

image upscaling

fit_enlarge=1

allows upscaling smaller images to the desired dimensions (will result in inferior image resolution)

Gravity

northwest

north

northeast

west

center | centre (default)

east

southwest

south

southeast

trim - more info

When using func=fit along with (trim=X), you can set gravity=trim. This way, upon a successful trim, the gravity will be resolved to a compass position so that the canvas will not be extended on the non-trimmed edges.

Margin

margin=X

If only one value is provided (margin=X), this sets the same minimum margin for all four edges. When two values are provided (margin=V,H), this sets the vertical (top and bottom) and horizontal (left and right) margins. If four values are listed (margin=N,E,S,W), they refer to the four image edges - north (top), east (right), south (bottom) and west (left).

By default, the margin is defined in pixels and applied before resizing. Alternatively, you can also use percentages (eg. margin=5p) of the destination size or absolute values in pixels (margin=100a) to define the margins.

When using a margin alongside trim=X and gravity=trim, if a successful trim is performed, the margins on the non-trimmed side is removed. For more details, see the Trim operation.

Examples
